Straight Side Single Crank Press
Home / Machines / Power Press / FSS
| Specification / Model | FSS-160 | FSS-200 | FSS-260 | FSS-300 |
|---|---|---|---|---|
| Pressure Capacity (Tons) | 160 | 200 | 260 | 300 |
| Length of Strokes (mm) | 200 | 200 | 250 | 300 |
| Strokes per minute - Fixed Speed (S.P.M) | 35 | 30 | 30 | 25 |
| Strokes per minute - Vairable Speed (S.P.M) | 25-40 | 20-35 | 20-35 | 20-30 |
| Rated Tonnage Point (mm) | 6 | 8 | 8 | 10 |
| Die Height (mm) | 400 | 400 | 450 | 450 |
| Adjustment of Slide (mm) | 80 | 100 | 100 | 100 |
| Area of Slide (mm) | 710x750 | 710x750 | 900x1000 | 1200x1200 |
| Area of Bolster (mm) | 900x800 | 900x800 | 1100x1000 | 1100x1000 |
| Specification / Model | FSS-350 | FSS-400 | FSS-500 | FSS-600 |
|---|---|---|---|---|
| Pressure Capacity (Tons) | 350 | 400 | 500 | 600 |
| Length of Strokes (mm) | 300 | 300 | 350 | 350 |
| Strokes per minute - Fixed Speed (S.P.M) | 25 | 25 | 20 | 20 |
| Strokes per minute - Vairable Speed (S.P.M) | 20-30 | 20-30 | 15-25 | 15-25 |
| Rated Tonnage Point (mm) | 12 | 12 | 13 | 13 |
| Die Height (mm) | 450 | 450 | 600 | 700 |
| Adjustment of Slide (mm) | 100 | 120 | 120 | 120 |
| Area of Slide (mm) | 1200x1200 | 1200x1200 | 1400x1400 | 1400x1500 |
| Area of Bolster (mm) | 1300x1300 | 1300x1300 | 1500x1500 | 1600x1500 |
Oversized 8-surface Slideways
Excellent for Heavy Load and Thick Plate
Straight side steel frame combined with
single crank design, that combined with
extra wide and extra long 8-surface
slideways making the machine ideal for
heavy duty and thick material pressing
operations.
Employ a newly designed high-torque,
split-type clutch and brake system, providing
highly sensitive motions and high efficiency.
Multi-function control system allows for
online with various automated devices, that
dramatically increases productivity.
