Home  /  Machines  /  Shearing machines / A-series

Features

Front Finger Guard

Prevent the user put the finger into shearing machine

Side Gauge

Standard 600 mm side gauge

Front support arm

Standard 600 mm front support arm

SPECIFICATION

A - Pneumatic Power Shear

Specification / Model A-5216
Cutting Length 1320 mm
Cutting Capacity - Mild steel 1.6 mm
Cutting Capacity - Stainless steel 0.9 mm
Front Support Arm 600 mm
Back Gauge 600 mm
Cutting Angle 1°40’
Packing Size (mm) 1920 x 850 x 1360
Packing Weight (KG) 722 kg

A - Air shear

  • All steel construction
  • High Carbon / Chrome Alloy-steel blades
  • 600 mm Front supporting arm
  • 600 mm Manual back gauge
  • Pneumatic Air power system
  • Foot Pedal
  • For small workshop and self-maker use
